Material

austenitic stainless steel with the designation AISI3014, EN 1.4301

Dimensions

Dimensions- depth 100 [mm]
– width 395 [mm]
– height 61 [mm]
– drain diameter: 50, 75, 110 [mm]

Advantages-

Advantages- the adjustable extension system can be adjusted to the thickness of the roof top insulation without the need for gaskets
– anchor flange and membrane clamp in the groove ensure secure grip of the membrane and roof flashing materials.
